Experience professional-grade wireless audio transmission with the Measy AU680A XLR Wireless Audio Transmitter and Receiver System. Designed for musicians, sound engineers, videographers, broadcasters, and event professionals, this versatile wireless audio solution delivers stable long-range transmission, ultra-low latency, and high-fidelity sound quality across a wide variety of audio equipment.
Supporting XLR, 6.35mm, 3.5mm, and RCA connectivity, the AU680A seamlessly integrates with microphones, mixers, speakers, instruments, cameras, and audio interfaces, making it an ideal solution for live performances, recording studios, conferences, and content creation.
Key Features
✅ Universal Audio Compatibility
- Multiple connection options include:
- XLR Input/Output
- 6.35mm Audio Port
- 3.5mm Audio Port
- RCA Audio Port
- Works with microphones, mixers, powered speakers, guitars, cameras, amplifiers, and recording equipment.
✅ Stable Long-Range Wireless Transmission
- Advanced wireless transmission technology ensures reliable signal performance.
- High-gain dual antennas help minimize interference.
- Wireless transmission range up to 100 meters in suitable environments.
✅ Ultra-Low Latency Performance
- Less than 0.5ms transmission delay.
- Ideal for live sound, professional video production, stage performances, and monitoring applications.
- Maintains accurate audio-video synchronization.
✅ High-Fidelity Sound Quality
- Wide frequency response of 20Hz to 20kHz.
- Clear, detailed audio reproduction with minimal distortion.
- Professional-grade sound suitable for studio and live applications.
✅ Professional Audio Specifications
- 64kHz / 16-bit digital sampling.
- Signal-to-noise ratio of 95dB.
- Dynamic range of 90dB.
- Excellent stereo channel separation.
✅ Durable Aluminum Alloy Construction
- Premium metal housing offers superior durability.
- Efficient heat dissipation for long-term reliability.
- Compact and portable design for easy transport.
✅ Real-Time Audio Control
- Receiver features gain adjustment controls.
- Convenient volume adjustment for different environments and devices.
- Helps optimize signal levels and output performance.
Ideal Applications
- Wireless microphones
- Live performances
- Stage productions
- Podcast recording
- Conference presentations
- Video production
- Studio monitoring
- Church audio systems
- Public speaking events
- Musical instruments
- Camera audio transmission
Transmitter Specifications
| Feature |
Specification |
| Operating Voltage |
3.6V-6V DC |
| Maximum Operating Current |
120mA |
| Frequency Range |
590-619MHz |
| Channels |
20 |
| Modulation |
GFSK |
| Baud Rate |
2Mbps |
| Channel Spacing |
4MHz |
| Frequency Stability |
±100kHz |
| Input Level |
Max 1.0Vpk |
| Input Impedance |
10kΩ |
| Wireless Range |
Up to 100m |
| Frequency Response |
20Hz-20kHz |
| Sampling Rate |
64kHz / 16-bit |
| Signal-to-Noise Ratio |
95dB |
| Distortion |
0.3% @ 1kHz |
| Dynamic Range |
90dB |
| Stereo Separation |
85dB |
Receiver Specifications
| Feature |
Specification |
| Operating Voltage |
3.6V-6V DC |
| Maximum Operating Current |
40mA |
| Receiver Sensitivity |
-90dBm |
| Frequency Range |
590-619MHz |
| Channels |
20 |
| Channel Selection |
Auto Scan & Manual Selection |
| Frequency Stability |
±100kHz |
| Output Impedance |
1kΩ |
| Wireless Range |
Up to 100m |
| Output Power |
30mW / 50mW |
| Frequency Response |
20Hz-20kHz |
| Delay Time |
<0.5ms |
| Sampling Rate |
64kHz / 16-bit |
| Signal-to-Noise Ratio |
95dB |
| Distortion |
0.3% @ 1kHz |
| Dynamic Range |
90dB |
| Stereo Separation |
85dB |
Connectivity Options
- XLR × 2
- RCA × 1
- 6.35mm Audio Jack × 1
- 3.5mm Audio Jack × 1
Benefits
✔ Wireless freedom up to 100 meters
✔ Ultra-low latency for professional applications
✔ Clear, distortion-free audio transmission
✔ Broad device compatibility
✔ Durable aluminum alloy construction
✔ Adjustable gain and volume controls
✔ Compact and portable design
✔ Suitable for indoor and outdoor use
Why Choose the Measy AU680A?
The Measy AU680A Wireless Audio System combines professional sound quality, dependable wireless performance, and exceptional versatility in a compact metal chassis. With support for multiple audio interfaces, long-range transmission, ultra-low latency, and studio-quality audio reproduction, it's an ideal solution for performers, content creators, audio engineers, and presenters who require reliable wireless audio connectivity.
Cut the cables without sacrificing audio quality and enjoy professional wireless sound with the Measy AU680A XLR Wireless Audio Transmitter & Receiver Set.
